Access Control Machine

Access control machine

Concept:

The access control all-in-one machine is an access control product that combines a card reader and a controller. There are independent types and networked types. Simply put, the access control all-in-one machine is a machine that integrates the access control board and card reader. The high-end ones also include a keyboard and a display screen. It only needs to be connected to the power supply to be used as a complete access control system.

The access control integrated machine is the core control equipment of the access control system. It has reliable data storage, no data loss after power failure, and integrates management and automatic control. Realize automatic management of access control, data can also be used for attendance, realize dual functions of access control and attendance, and can be seamlessly connected with the one-card system.

System composition

A standard set of access control all-in-one system is as follows:

Basic configuration: access control all-in-one, card, 12VDC power supply for access control, electric lock, exit button，

Optional equipment also includes: door closer, card reader, door sensor, doorbell, etc.

Function

1. No need to connect to a computer, you can perform system settings offline (add and delete cards, password modification, unlock time)

2. At the same time support three ways to open the door: swipe card to open the door, password to open the door, swipe card and password to open the door

3. Good safety performance, using anti-smashing engineering plastic shell, with anti-prying alarm and door magnetic alarm function

4. Three-color high-brightness LED and buzzer sound indication, easy to operate

5. Store 1000 user information; can add a card reader

6. Card reading induction time is less than 0.1 seconds, card reading distance: 3-20CM

7. With data power-off protection function, power-off data will never be lost

8. Equipped with input interface such as exit button, door sensor, and doorbell interface

9. The electric lock interface adopts relay output, normally open or normally closed output mode is optional

门禁一体机

概念

门禁一体机就是读卡和控制器合二为一的门禁控制产品，有独立型的也有联网型的。简单而言，门禁一体机就是集门禁控制板读卡器于一体的机器，高档点的还包括键盘跟显示屏，只需要接上电源就可以当完整的门禁系统使用了。

门禁一体机是门禁系统的核心控制设备，具有数据存储可靠，掉电数据不丢失，集管理和自动控制为一体。实现门禁的自动化管理，数据还可用于考勤，实现门禁考勤双功能，同时与一卡通系统可以无缝连接。
